I am patent illustrator and having an ability to produce patent drawing including technical, medical, electronic circuit drawing and much more according to the guideline set by patent office

I am a mechanical engineer having a excellent knowledge about the drawing and also have a working experience as a patent illustrator where i have produce different kind of drawings such as utility drawings, design drawings, medical equipment, fabric drawing, electronic circuits and much more.
I have a good hand on experience for shading to show the shape of the product as per guideline set by USPTO, PCT, WIPO, JPO e.t.c.
I am also capable to produce high quality and consistent drawing which is the vital need of the client as well as patent office.
For consistency of the drawing, i am also used to prepare the 3D model if it is possible to produce, as i have a good hand on experience to prepare a 3D model using CAD softwares like Autocad, creo, inventor e.t.c.
I have an ability to produce a drawing from the images, hand drawn sketches, screenshots, hand written note, videos or any kind of thing in which your invention and detail is clear and easily adaptable.

Work Terms

***Price and time may be vary according to the complexity and quantity of drawing***
*****Please contact me before placing an order*******
******We do not compromise in quality******
